Additional Features:

• Frequency range: 100 kHz to 110 GHz sensor dependent
• Power Range: -70 to 44 dBm, sensor dependent
• Automatic calibration and zeroing
• Selectable resolution and duty cycle
• Save and recall of meter settings
• Instrumentation accuracy: ±0.02 dB or ±0.5%
• Compatible with the Agilent 8480 series of power sensors

The Agilent 70100A is a single-slot power meter module with features and capabilities similar to the Agilent 437B power meter. As part of the Modular Measurement System (MMS), it is ideal where many power meters are required for a test system. The Agilent 70100A is compatible with the Agilent 8480 series of power sensors.
